450 tph Dust controlled hopper for cargo handling at seaport
General Information:
| Place of Origin: | China |
| Brand Name: | SSI |
| Certification: | manufacture certificate |
| Model Number: | 30 cube meter |
|
Product: |
Dust Controlled Hopper |
Color: |
Blue |
|
Type: |
Dust Proof |
Painting: |
European Brand |
|
Output: |
450t/h |
Model: |
30 M³ |
|
Character: |
Stationary |
Wear Plate: |
Hardox 500 |
|
High Light: |
Specially designed according to the application situatioln. Whole Transporting on ro-ro ship, quick and economically. Reliable, reputation,high quality and cost effective. |
||
Product Description
The SSI Eco hopper is widely used at the port for bulk cargo transfer from vessel to truck or conveyor belt. The SSI ECO hopper is designed as a dust controlled, grab or belt conveyor unloading hopper, is an economical and ecologically sensitive solution. It`s customized designe to suit the property of any bulk materials. And fulfill all needs for the efficient import of dry bulk materials.
The SSI ECO hoppers is designed base on the client`s specification requirement.
The SSI dust controlled hoppers is designed to solve the major issue for all ports when handling bulk materials. The SSI Eco hoppers become more in terms of dust controlled and space saving design, they must remain simple to set up and operate.
Technical specification
|
output |
450t/h |
|
material |
grain |
|
density |
0.83t/m³ |
|
volume |
30m³ |
|
application |
discharge to truck |
|
pressure on each support landing |
30t |
|
full load of hopper |
80t |
|
size of discharge opening |
400mm*400mm |
|
power of fan motor |
22kw*3 |
|
noise |
less than 80 DB |
|
travel speed |
10m/min |
|
power consumption |
105kw |
|
dead weight |
75t |
General drawing
Applications
Case 1
Case 2
Case 3
